COMPONENTES
Cuadro
Mako 4, XCO Geometry BGC, 113mm travel with integrated IN-LINK suspension, Full carbon HM2X, moncoque, resin HEXCEL HexPly, bearings full ball ISB VMAX, BB92 botton bracket, full internal cable system ICS2, Integrated headset OH2S 1-1/2", Post Mounted brake PMS, 29"x2.40 maximun tyre, BOOST Thru axle 148x12, UDH standar, weight 1795g (without hardware)
Horquilla
Rock Shox SID Base, Damper Rush RL, 15x110mm Maxle Stealth, Rake 44mm, Tapered steerer, 35 mm straight wall aluminium Fast Black, 2 Position Lockout remote, weight 1686g, 110mm travel
Material
Full carbon fiber HM2X
Manillar
Avanforce AF1 XCO, UD carbon, 31,8mm, wide 740mm, Backsweep 5°, Upsweep 3°, weight 190g
Tija Sillin
Avanforce 0 offset, 31,6 x 400mm
Sillin
Fizik Taiga alloy rail
Patilla
UDH Universal Derailleur Hanger
Amortiguador
Rock Shox SIDLuxe ULTIMATE BERRIA MAKO 3 WC XCO Tuning, Debon Air, Lockout remote 2 POS adjustement, Trunion 165X45mm, weight 227g, 105mm travel
GRUPO CAMBIO
Cambio
SHIMANO XT RD-M8100 SGS, Shadow Plus, 12 SpeedManetasSHIMANO SLX-M7100-R, Rapidfire PlusPiñonesSHIMANO SLX CS-M7100-12, 10-51TCadenaSHIMANO M7100BielasRACEFACE AFFECT 34T 170-175mmFrenosSHIMANO XT M8100 Disc 180/F and 160/R SM-RT80 rotor
RUEDAS
Neumático
Vittoria Barzo 2.25"X 29", Tubeless Ready, GRAPHENE 2.0 120 TPI, weight 660g
Rueda
FULCRUM RED ZONE 99, Alloy, internal width 23 mm, max. weight 120kg, weight 1850g
